Ignition Switch

Ignition Switch - 3 Position Magneto

• Back Up Nut: Anodized Steel
• Face Nut: Hex Plastic with Snap On Rubber Cap
• Hole Size: 7/8"
• Length: Long: 1 1/8" maximum panel thickness
• Material: Marine grade glass-filled Polyester
• Rated Choke: 7 Amp @ 12v DC
• Rated Ignition: 15 Amp @ 12v DC
• Rated Solenoid: 30 Amp @ 12v DC
• Terminal Type: 6 Screw Tab
• Switch Function: Off - Run - Start
• Type: 3 Position Magneto
• Push to choke
• Maximum corrosion protection - eliminates oxidation
• Inner seal between cylinder lock and contact plate
• Non-conductive housing eliminates potential shorts

Toepassingsgebied
• Marine

Aantal per motor
• 1

Fabrikant
• Sierra

Vervangt
• Cole-Hersee M832BP
